ET-PARROT 70/220…240 I Easy Control Gear - Easy Control Gear
Easy Control Gear

ET-PARROT 70/220…240 I

Order Code: ETPARROT70-OS

Stock Level: Delivery in 3-5 Days

$18.00 - $18.00
$18.00
$18.00 - $18.00
$18.00

Got a question about this product? Get in Touch

Having trouble finding what you're looking for?

We can source most electrical products.
Contact us, we're here to help.
Product family benefits
  • Very low power loss thanks to high efficacy
  • Protective operation throughout the entire partial-load range for long lamp life
Areas of application
  • Effect and accent lighting
  • Living rooms
  • Object lighting
  • Conference rooms
  • Restaurants
  • Recessed and surface-mounted furniture luminaires
  • Shop lighting
  • Event rooms

  • Technical Data

    Electrical data

    Lamp wattage

    20…70 W

    Maximum output power

    70 W

    Line current

    0.30 A


    Nominal voltage

    220…240 V

    Power factor λ

    0.95


    Operating frequency

    50 kHz


    Nominal output voltage

    11.9 / 12.0 V


    Input voltage AC

    198…264 V

    Mains frequency

    50…60 Hz

    System wattage

    74.00 W

    Efficiency in full-load

    94 %

    Input voltage range

    220…240 V

    Max. ECG no. on circuit breaker 10 A (B)

    37

    Max. ECG no. on circuit breaker 16 A (B)

    59

    Galvanic isolation primary/secondary

    4.00 kV


    Inrush current

    0.45 A

    Dimensions & weight

    Length

    128.0 mm

    Width

    38.0 mm

    Height

    31.0 mm

    Mounting hole spacing, length

    119.0 mm

    Cable cross-section, input side

    0.75 mm²

    Cable cross-section, output side

    0.75 mm²

    Wire preparation length, input side

    12 / 6.0 mm


    Wire preparation length, output side

    12 / 6.0 mm


    Product weight

    115.00 g

    Temperatures & operating conditions

    Ambient temperature range

    0…+45 °C

    Maximum temperature at tc test point

    70 °C

    Additional product data

    Design / version

    Compact

    Capabilities

    Dimming method

    Trailing- or leading-edge phase control for inductive load dimmers

    Overload protection

    Automatic reversible

    Overheating protection

    Automatic reversible

    Short-circuit protection

    Automatic reversible

    Max. cable length to lamp/LED module

    2.0 m

    Cable/wire types, input side

    H03VV-F 2x0.75 mm²

    Cable/wire types, output side

    H03VV-F 2x0.75 mm²

    Dimmable

    Yes

    Dimming range

    0…100 %

    No-load proof

    Yes

    Suitable for fixtures with prot. class

    II

    Intended for no-load operation

    No

    Certificates & standards

    Approval marks – approval

    VDE / EAC

    Standards

    Acc. to EN 61347/Acc. to EN 55015/Acc. to EN 61000-3-2/Acc. to EN 61547

    Type of protection

    IP20

Specification


Dimensions
