Built-in 0~10Vdc or PWM signal dimming function
Output current level selectable by DIP S.W.
Built-in active PFC function
Protections: Short circuit / Over voltage / Over temperature
Other features:
180~295VAC input only
Cooling by free air convection
Temperature compensation function by external NTC
No load power consumption <1.2W@AC always on
Fully isolated plastic case
Class power unit, no FG
Built-in 12V/50mA auxiliary output
Suitable for LED lighting applications
Power supplies synchronization function up to 10 units
3 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
60
Output Voltage
Choose Option
Dimmable (Type)
0~10Vdc & PWM signal
Dimensions
123.5x 81.5x 23
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN55024, EN61547 light industry level (surge 2KV), criteria A
Input Voltage
180~295VAC 254~417VDC
Safety Standards
UL8750, ENEC EN61347-1, EN61347-2-13,EN62384 independent approved
Output Voltage Options
Single
Working Temperature
-40~+85°C
PDF Datasheet
LCM-60-spec_2.pdf
Specification
Dimensions
